3.2-4mm Ultra White Solar Glass

3.2-4mm Ultra White Solar Glass

Photovoltaic Glass, Building Glas, Low Iron Glass

Description

Basic Info
  • Model NO.: 3.2-4mm
  • Appearance: Flat Tempered
  • Steel Degree: Super-Tempered Glass
  • Fragment State:
  • Flatness: High Class
  • Max Size: 2250mm*3300mm
  • Trademark: YaoHua Glass
  • Specification: According to customer requirements
  • HS Code: 70071900
  • Shape: Flat
  • Standard: CCC,GB15763.2-2005
  • Thickness of Flat Tempered Glass: 3.2mm,4.0mm
  • Technics: Physically Tempered
  • Usage: Building, Solar Cell
  • Color: Clear / Ultra Clear (Low Iron)
  • Transport Package: Seaworthy Wooden Crates or Plywood Crates
  • Origin: Anhui, China
Product Description

3.2-4mm Ultra White Solar Glass
3.2mm/4.0mm Tempered Ultra Clear and Low Iron Solar glass.

The Solar glass is a special glass that is laminated into a solar cell, It can be able to use solar radiation to generate electricity, and has a related current extraction device and cable.With the outstanding characteristics of the high solar lights transmittance,the low reflectance,the low iron,the high mechanical strenght and the high flatness.the application is very extensive.

Specification:
Standard Thickness  3.2mm and 4mm
 Thickness Tolerance  3.2+-0.20mm; 4.0mm+-0.30mm;
 Max size  2250mm*3300mm
 Solar Transmittance (3.2mm)  ≥ 91.6%
 Iron Content  ≤ 120ppm Fe2O3
 Poisson's Ration  0.2
 Density 2.5g/CC
 Young's Modulus   73. Gpa
 Tensile Strength  42MPa
 Hemispherical Emissivity   0.84
 Epansion Coefficient  9.03*10-6/º C
 Softening Point  720º C
  Annealing Point  550º Cv

Features:
1.High solar lights transmittance
2.The low reflectance: visible light reflectance is less than 7.30%
3.Low iron:glass has only 0.012% of iron content;
4.The High mechanical strenght ,the strength is 3-5 times of ordinary annealed glass
5.Safety:if it is broken, it usually breaks into relatively small pieces, which are less likely to cause serious injury.


YaoHua Glass Solar Glass Production Lines:
3.2-4mm Ultra White Solar Glass
3.2-4mm Ultra White Solar Glass


YaoHua Glass Packing:
3.2-4mm Ultra White Solar Glass

YaoHua Glass Competitive Advantages:

a. 12 years experience in glass production.
b. Direct factory price, quick delivery, professional package and container loading design.
c. Quality assurance. ISO 9001:2008 Quality System Certification. Glass products with CE certification,
    SGS test reports.

d. Full range of glass supply, offering one-stop purchase.


FAQ:
1. MOQ:  500 Square Meters
2. Payment terms: T/T; 30% advance payment, 70% balance against the copy B/L.
3. Delivery time: Normally, goods will be delivered to the cargo vessel within 30 days after receiving the
   advance payment. In the case of urgent order, we can deliver them within 15 days.
4. Shipping portShanghai port
5. Samples: Small glass samples can be provided at our cost.if you want us to provide big size sample according to your requirements, you should pay the cost of production
